15L
| Model | VITA10 30 | VITA15 45 | VITA20 60 | VITA60 120 |
| Capacity/L | 7 | 10 | 15 | 35 |
| Added Batch/L | 1.5-5.0 | 2.5-7.5 | 3-10.5 | 8-24.5 |
| Min/Batch | 8-10 | 8-10 | 9-12 | 10-15 |
| Hourly Production/L | 10-30 | 15-45 | 20-60 | 60-120 |
| Voltage | 220/380 | 220/380 | 220/380 | 220/380 |
| Frequency | 50/60 | 50/60 | 50/60 | 50/60 |
| Phase | 1/3 | 1/3 | 3 | 3 |
| Refrigerant | R404A | R404A | R404A | R404 A |
| Condenser | Water/Air | Water/Air | Water/Air | Water/Air |
| Power/KW | 3 | 4.45 | 6 | 7.75 |
| Dimension/CM | 69.5*85*140 | 69.5*85*140 | 69.5*85*140 | 71*121*141.5 |
| Net Weight/KG | 225 | 270 | 315 | 450 |
1. Freezing cylinder： Strong Stainless steel dasher with floated blade cutter results in perfect fit with cylinder wall make it more efficient in freezing and improve the smoothness of the finished product. The cylinder is designed and tested to ensure a perfect combination in terms of chilling performance, freezing and micro-crystallization speed as well as optimized air incorporation
2. Touch Screen&Manual： The user can choose to operate the machine in Touch mode or in the traditional Manual mode. The PLC touchscreen has clear and intuitive icons that enable to manager and monitor each operating phase
3. Stirrer：Special design helicoidal stirrer with blade variable convergence and high-performance scrapers.
4. Blades: The material blades are made of is provide with EC marking for use in food handling equipment. It can be disassembled easily, convenient for fast cleaning.
5. Retractable washing nozzle：Retractable washing nozzle to speed up cleaning, quite save water
6. Gelato output：Wide outlet with ingenious handle, quick extrude out and minimal flavors overlap, improve production ability
Nanjing Prosky Food Machinery Manufacturing Co.,Ltd located in Nanjing Lishui Economic department zone which is very close to Nanjing Lukou International Airport. Prosky has more than ten years' experience in professional Italy Artisan gelato machinery field and devotes to become the top-class Italy gelato equipments manufacturer and facilitator in China.
We Porsky with ISO9001 has perfect production and quality control system. Prosky machines have passed CE and SGS certification. Meanwhile the agitator system of pasteurizer has been awarded as national utility model patent.We Prosky has signed a lot cooperation papers with nanjing famous universities to create innovative atmosphere and sustainable development .
We Prosky is professional in Milk Pasteurizer,Batch Freezer,Blast Freezer,Display Freezer, Ice Cream Combined Machine and so on and can also make customized machine to meet Domestic Europe,North America.South America and all worldwide demands.
